Helm MKII AIR
Tenedores
Helm MKII AIR
Tenedores
Este Helm MKII con descuento es un producto con imperfecciones.
Este producto está agotado hasta nuevo aviso.
Helm MKII es nuestra Horquilla de bicicleta de montaña altamente versátil, ideal para bicicletas downcountry, trail y enduro. La diseñamos para que sea súper suave pero a la vez con soporte, y puede adaptarse a casi cualquier forma en que desees usarla.
Es la pieza que falta cuando tu bicicleta se siente superada y dura en senderos accidentados, dándote la confianza para lanzarte en secciones rocosas con menos vacilación.
Sin piezas adicionales, Helm puede configurarse con un recorrido de entre 120mm y 160mm. También cuenta con un amplio rango de ajustes de resorte de aire y amortiguador, donde cada posición representa un cambio significativo, facilitando encontrar una configuración que te encante.
- Navegación Suave: Las actualizaciones al amortiguador y sellos del MkII fueron diseñadas para máxima suavidad
- Soporte Ajustado: La amortiguación de compresión independiente te permite añadir soporte para impactos grandes mientras mantienes una suspensión sensible para suavizar las vibraciones del sendero.
- Manejo Seguro: El chasis de Helm es lo suficientemente robusto para conducción agresiva, con la rigidez torsional para que tu rueda delantera vaya donde la apuntes.
- Ajustes que Puedes Sentir: Los ajustes independientes y de amplio rango para compresión a alta y baja velocidad producen cambios significativos con cada clic.
- Hecho a Mano: y probado individualmente en dinamómetro aquí mismo en Carolina del Norte.
- Estilo Único: Con 8 kits de calcomanías de colores y 4 opciones completas de color Chroma Studio, tienes la oportunidad completa de hacer que tu bicicleta destaque.
- Recorrido Ajustable: Cambio fácil de recorrido en casa (120mm – 160mm) sin piezas adicionales.
- Dos Opciones de Resorte: resorte de aire = máxima capacidad de ajuste resorte de espiral = mejor sensibilidad y sensación de adherencia al terreno
- Sistema único de ajuste de volumen de aire que te permite ajustar la cantidad perfecta de soporte en la mitad y final del recorrido.
Las Horquillas Helm de 29 pulgadas vienen en acabado negro brillante con calcomanías negras mate y las Horquillas Helm de 27.5 vienen en acabado negro mate con calcomanías negras brillantes.
Los pedidos que incluyen suspensión se fabrican por encargo y se envían en 5-10 días.
Todas las devoluciones de Horquillas de 29″ están sujetas a una tarifa de reposición del 20%.
Todas las Horquillas de 27.5″ son venta final.
Edición Limitada: Consulta nuestra colección completa de estas muy codiciadas Horquillas Helm.
Suspension is built to order, ships in 5-10 days
30-Day returns
Free US shipping on orders $150+
¿El producto que desea está agotado? Envíe un ticket o llame al (828) 641-9560 y nuestro equipo de soporte le ayudará a encontrar una solución.
- MMMichael M.ReviewingHelm MKII 29"I recommend this productRated 5 out of 5 stars3 years agoHelm MKII Air 29 - 160mm - 44mm Offset - BAG0685
The Helm is the plushest fork I have ridden. I was amazed at how adjustable this fork is and how easily I can adjust the travel. The negative chamber leaves no questions on equalizing air. And the ride? AMAZING! So much fun and so plush in every environment, but especially when things get rowdy! Not satisfied with your current setup, don't hesitate giving the Helm a go. You won't be disappointed!
- LALance A.Verified BuyerReviewingHelm MKII 27.5" (Blemished) Air - 29" - 160mm / Black / BAG0685BI recommend this productRated 5 out of 5 stars1 year agoA deal so amazing, I still can't believe that it exists
I'd been wanting to upgrade the fork on my e-bike for a while now but never thought I'd see a Cane Creek Helm Mk II with such a huge discount on it. It HAD to be too good to be true...right? It arrived a couple days later (I live in WNC less than an hour's drive of CC HQ) & I was floored when I opened the box. The "blemish" was a small spot, maybe the size of my thumbnail, where there must have been some contaminant on the fork crown when it was anodized. It was otherwise--and most importantly--functionally perfect! But that enormous discount for such a small imperfection?!? Wow. Once I had it installed on my e-bike, you can't even see the "blemish" unless I point it out.
I knew the fork was going to perform well on the trails at Ride Kanuga, but any expectations I had were vastly exceeded. It's plush like your favorite recliner but handles like a Ferrari (if a MTB could be a Ferrari). The old fork was a 160mm so I didn't need to adjust the travel. After a couple rides, I bottomed out a few times so I've since installed the air volume piston to increase progressiveness, which only took a few minutes to install thanks to CC's awesome support videos.
If I had to do it all over again, I should have bought two.
- MMMichael M.ReviewingHelm MKII 29"I recommend this productRated 5 out of 5 stars3 years agoHelm MKII Air 29 - 160mm - 44mm Offset - BAG0685
The Helm is the plushest fork I have ridden. I was amazed at how adjustable this fork is and how easily I can adjust the travel. The negative chamber leaves no questions on equalizing air. And the ride? AMAZING! So much fun and so plush in every environment, but especially when things get rowdy! Not satisfied with your current setup, don't hesitate giving the Helm a go. You won't be disappointed!
- LALance A.Verified BuyerReviewingHelm MKII 27.5" (Blemished) Air - 29" - 160mm / Black / BAG0685BI recommend this productRated 5 out of 5 stars1 year agoA deal so amazing, I still can't believe that it exists
I'd been wanting to upgrade the fork on my e-bike for a while now but never thought I'd see a Cane Creek Helm Mk II with such a huge discount on it. It HAD to be too good to be true...right? It arrived a couple days later (I live in WNC less than an hour's drive of CC HQ) & I was floored when I opened the box. The "blemish" was a small spot, maybe the size of my thumbnail, where there must have been some contaminant on the fork crown when it was anodized. It was otherwise--and most importantly--functionally perfect! But that enormous discount for such a small imperfection?!? Wow. Once I had it installed on my e-bike, you can't even see the "blemish" unless I point it out.
I knew the fork was going to perform well on the trails at Ride Kanuga, but any expectations I had were vastly exceeded. It's plush like your favorite recliner but handles like a Ferrari (if a MTB could be a Ferrari). The old fork was a 160mm so I didn't need to adjust the travel. After a couple rides, I bottomed out a few times so I've since installed the air volume piston to increase progressiveness, which only took a few minutes to install thanks to CC's awesome support videos.
If I had to do it all over again, I should have bought two.
RESEÑAS
ESCUCHA LO QUE OTROS TIENEN QUE DECIR
- MMMichael M.ReviewingHelm MKII 29"I recommend this productRated 5 out of 5 stars3 years agoHelm MKII Air 29 - 160mm - 44mm Offset - BAG0685
The Helm is the plushest fork I have ridden. I was amazed at how adjustable this fork is and how easily I can adjust the travel. The negative chamber leaves no questions on equalizing air. And the ride? AMAZING! So much fun and so plush in every environment, but especially when things get rowdy! Not satisfied with your current setup, don't hesitate giving the Helm a go. You won't be disappointed!
- LALance A.Verified BuyerReviewingHelm MKII 27.5" (Blemished) Air - 29" - 160mm / Black / BAG0685BI recommend this productRated 5 out of 5 stars1 year agoA deal so amazing, I still can't believe that it exists
I'd been wanting to upgrade the fork on my e-bike for a while now but never thought I'd see a Cane Creek Helm Mk II with such a huge discount on it. It HAD to be too good to be true...right? It arrived a couple days later (I live in WNC less than an hour's drive of CC HQ) & I was floored when I opened the box. The "blemish" was a small spot, maybe the size of my thumbnail, where there must have been some contaminant on the fork crown when it was anodized. It was otherwise--and most importantly--functionally perfect! But that enormous discount for such a small imperfection?!? Wow. Once I had it installed on my e-bike, you can't even see the "blemish" unless I point it out.
I knew the fork was going to perform well on the trails at Ride Kanuga, but any expectations I had were vastly exceeded. It's plush like your favorite recliner but handles like a Ferrari (if a MTB could be a Ferrari). The old fork was a 160mm so I didn't need to adjust the travel. After a couple rides, I bottomed out a few times so I've since installed the air volume piston to increase progressiveness, which only took a few minutes to install thanks to CC's awesome support videos.
If I had to do it all over again, I should have bought two.
"Mezclar niveles increíbles de control, niveles impresionantes de sensibilidad a pequeños baches y una gran cantidad de ajustes deja la puerta abierta de par en par al buscar esa configuración definitiva."
– Jim Bland, mecánico de la Copa del Mundo
Helm MKII Air
Especificaciones del producto
2080 gramos
Compresión de alta velocidad, compresión de baja velocidad, rebote de baja velocidad
Sistema de doble resorte de aire. Resortes de aire positivos y negativos de alto volumen
35mm
180 mm. *Si está utilizando un freno Hope Tech en una horquilla Helm, necesitará usar un rotor de 200 mm con el adaptador adecuado.
Optimizado para 130-160 mm de recorrido
Interno, incrementos de 10 mm (de 160 mm a 130 mm)
Incluye 2 espaciadores de recorrido
"D-Loc" eje pasante de 15 mm con perno / espacio BOOST de 15 mm x 110 / 44 mm
64 mm de ancho por 749 mm de alto (29) / 75 mm de ancho por 739 mm de alto (27.5+)
Helm MKII Coil
Especificaciones del producto
2340 gramos
Compresión de alta velocidad, compresión de baja velocidad, rebote de baja velocidad
Compresión de alta velocidad (10 posiciones)
Compresión de baja velocidad (17 posiciones)
Rebote de baja velocidad (10 posiciones)
Sistema de ajuste de recorrido indexado
Ajuste de precarga del resorte
35mm
180 mm. *Si está utilizando un freno Hope Tech en una horquilla Helm, necesitará usar un rotor de 200 mm con el adaptador adecuado.
Optimizado para 130-160 mm de recorrido
Interno, incrementos de 10 mm (de 160 mm a 130 mm)
(No se requieren piezas adicionales)
"D-Loc" eje pasante de 15 mm con perno / espacio BOOST de 15 mm x 110 / 44 mm
64 mm de ancho por 749 mm de alto (29) / 75 mm de ancho por 739 mm de alto (27.5+)
Resorte de 35 lb – AAG0421 ROJO – (ciclista de 90-120 lbs)
Resorte de 45 lb – AAG0422 NEGRO – (ciclista de 120-160 lbs)
Resorte de 55 lb – AAG0424 VERDE – (ciclista de 160-200 lbs)
*El resorte de 55 lb viene preinstalado de fábrica
Resorte de 65 lb – AAG0426 AZUL – (ciclista de 200-240 lbs)
Con cambios en la cantidad de recorrido interno, la posición del ciclista en la bicicleta, el ángulo de la dirección de la bicicleta y la habilidad/estilo del ciclista, las tasas de resorte variarán. Para asistencia, por favor contacte a Cane Creek o a su Centro de Servicio Certificado más cercano
Resorte de bobina ligero de 55 lb incluido de fábrica
Resortes de 35-45-55-65 lbs/pulg disponibles en nuestra página de Piezas y Accesorios
Documentos técnicos
